Final year project proposal decription
Background:
COMET has being developed using a novel design
method called ACCORD, which combines software
engineering techniques, such as component-based and aspect-oriented software
development into real-time system software development. ACCORD enables design of
real-time systems by first decomposing a system into a set of components,
followed by the decomposition of the real-time system into a set of aspects.
Components and aspects in the ACCORD (thus, also in the COMET) are designed and
implemented using a real-time component model called
RTCOM.
The initial
COMET configuration (baseline COMET), implemented so far, corresponds only to
the component-based decomposition of an embedded real-time database system.
Aspect-oriented decomposition has been performed on a conceptual level, but has
not been implemented yet.
The baseline
COMET consists of the following components: user interface component, indexing
component, memory handling component, and transaction manager component. This
baseline configuration does not support concurrent transactions, and it is
developed for non-concurrent real-time systems, where only one task can be
active at one point in time.
The goal of the project:
The goal of
the project is to extend a COMET component library and
create an aspect library by making a concurrent COMET configuration. This
implies implementation of adequate scheduling and concurrency control policies
into the baseline COMET framework. Moreover, the goal is also to perform a study
of impact of the ACCORD design as opposed to pure component-base design of the
COMET system. Hence, two implementations of scheduling and concurrency control
in COMET should be made: one according to ACCORD and RTCOM, i.e., using both
components and aspects, and the other according to component-based software
development, i.e., using components only. It is expected that the project
results in 2 RTCOM components, namely scheduling and locking components, and 4
aspects, namely scheduling and concurrency control (1 for each policy chosen),
and 4 non-RTCOM components, namely 2 scheduling (one for each scheduling policy
chosen) and 2 concurrency control components (where locking and concurrency
control are encapsulated within one component). As scheduling and concurrency
control are strongly related, we expect strong dependencies between the two that
need to be handled in the project.
Finally, the
project should result in the answer to the following question:
 |
What is the
trade-off between using mechanisms within RTCOM together with aspects as
opposed to usage of pure components (drawback and benefits in terms of
maintainability, code size, memory footprint, exchangeability of features in
the database) |
Following steps/stages should be performed in the
project:
(I) Background preparation stage:
|
Study existing scheduling and concurrency control policies; |
|
Study ACCORD design method and get a full understanding of
the RTCOM; |
|
Study current COMET implementation and design
documentation; |
|
Make a detail time-plan with all steps of the project; |
(II)
Design stage and refinement stage:
|
Pick
(at least) two scheduling and two concurrency control algorithms, with
distinct characteristics (e.g., optimistic vs.
pessimistic concurrency control policy). The choice should be motivated in
terms how it fits the COMET, and ACCORD. |
|
Make a design of the concurrency control aspect, and the
locking component. The locking component should, as defined by RTCOM, consist
all mechanisms needed by both policies. |
|
Determine the crosscutting impact of the aspect to the
existing COMET, i.e., to which degree the other
existing COMET components should be modified to support concurrency control.
|
|
Make a design of the scheduling aspect, and the scheduling
component (the scheduling component should, as defined by RTCOM, consist all
mechanisms needed by both policies. |
|
Determine the crosscutting impact of the scheduling aspect
to the existing COMET, i.e., to which degree the other components should be
modified to support concurrency control. – Emphasis is on the relation between
concurrency control and locking component and scheduling component and
scheduling aspect. |
|
Make a design of the concurrency control component
(performing locking + concurrency control), and study or predict the impact of
having concurrency control and locking into one component (as opposed to
aspectual implementation) of the remaining COMET configuration. |
|
Make initial predictions of possible benefits and drawbacks
of RTCOM approach as opposed to pure component-based approach |
|
According the findings, at the end of this stage the thesis
goals could be redefined to reflect the conclusions obtained while making the
design decisions and observing the impact of the design to the system and the
initial thesis goals. |
(III)
Implementation phase:
|
Implement both aspectual and component-based approach and
(i.e., 2 concurrency control aspects and 2
scheduling aspects + locking component + scheduling component + concurrency
control component) |
(IV)
Performance analysis phase:
|
Develop adequate tests to answer the following question
 |
What is the trade-off between using mechanisms and RTCOM
together with aspects a opposed to usage of pure components (drawback and
benefits in terms of maintainability, code size, memory footprint,
exchangeability of features in the database) |
|
|
Perform tests and derive conclusions |
Background knowledge that would help candidate student:
| Basics in database systems |
| Basics in real-time systems |
| C and C++ |
Project set-up:
|
Two students are needed to carry out
the work, and they are, most likely, going to closely work on the project. One
student should work on scheduling and the other on concurrency control issues.
|
|
After the (I)
phase of the project student should prepare a description of its thesis goals
and the problem description. |
|
After the (II)
phase of the project, the goals of the project are refined and could be
adjusted further to reflect the workload and conclusions reached in (III). |
|
During each phase of the project
student should document her/his findings, conclusions, design,
implementations, and results, so that the thesis writing process is initiated
and carried out during each stage in the project |
Proposed time-framework:
(I)
Background preparation stage - 3 weeks
(II)
Design stage and refinement stage – 5 weeks
(III)
Implementation phase – 5 weeks
(IV)
Performance analysis phase – 5 weeks
(V)
Thesis wrap-up – 2 weeks
The project
lasts for 20 weeks, and is done by both students in parallel.
Research areas covered by the project:
Work on the
thesis provides a student with a deeper knowledge and understanding of the
following areas of computer science/engineering:
|
Advanced
software engineering techniques, namely component-based software development
and aspect-oriented software development |
|
Real-time
systems |
|
Embedded systems |
|
Database systems |
